RAVENOL Hydraulikoel TS 46 (HLP) is optimal alloyed mineral hydraulic oil with a high performance level and a wide application area of the whole industry.
RAVENOL Hydraulikoel TS 46 (HLP) with efficient additives offers an excellent corrosion protection even under extreme loads. The behaviour of sealing materials is neutral.
RAVENOL Hydraulikoel TS 46 (HLP) is characterised by good viscosity temperature behaviour, a high aging resistant and a solid corrosion protection.
Application Note
RAVENOL Hydraulikoel TS 46 (HLP) is for universally use in all hydraulic systems.
RAVENOL Hydraulikoel TS 46 (HLP) is recommended in high performance hydraulic systems with high pressure pumps of all types, in sensitive control systems.
RAVENOL Hydraulikoel TS 46 (HLP) is used for hydraulic systems in agriculture, to supply small gearboxes and for use in circulating systems.
Characteristics
- a high performance level
- a very good viscosity temperature behaviour
- a high aging resistant
- an excellent corrosion protection
- a solid corrosion protection
- neutrality of sealing materials
Technical Product Data
| Property | Unit | Data | Audit |
|---|---|---|---|
| Density at 20 °C | kg/m³ | 857,0 | EN ISO 12185 |
| Colour | hellgelb | VISUELL | |
| Viscosity at 100 °C | mm²/s | 7,2 | DIN 51562-1 |
| Viscosity at 40 °C | mm²/s | 47,0 | DIN 51562-1 |
| Viscosity Index VI | 113 | DIN ISO 2909 | |
| Pourpoint | °C | -27 | DIN ISO 3016 |
| Flashpoint | °C | 238 | DIN EN ISO 2592 |
| FZG-Test A/8.3/90 Damage loading step | %wt. | 12 | DIN 51354/2 |
| Aging stability, TOST | st | 2000 | DIN 51587 |
| Demulsification | 40ml/40ml/10min. | DIN 51757 |
All indicated data are approximate values and are subject to the commercial fluctuations.
