RAVENOL Racing Gearoil

Category: Gear oil for manual transmissions and drive axis
Item number: 1221111
Specification: API GL-5 + LS
Oil type: Full synthetic
Application: Racing
Technology: USVO®, Racing

RAVENOL Racing Gearoil is a modern, PAO (poly-alpha-olefin) based full synthetic racing gear oil with USVO® Technology.

RAVENOL Racing Gearoil was developed as manual and differential oil for use in racing vehicles. The USVO® technology offers high performance, improved gear protection and optimized gear cleanliness for your vehicle. Special additives guarantee limited slip properties, a high load carrying capacity, stable viscosity, optimum wear protection, low foaming, proper lubrication and reducing the heating of the transmission.

RAVENOL Racing Gearoil offers excellent anti-wear properties and an optimum viscosity-temperature behavior.

Application Note

RAVENOL Racing Gearoil is used as special race oil based on PAO for limited-slip differentials of race cars.

Characteristics

  • A stable high-pressure lubricating oil film even at high temperatures and under high stress.
  • Excellent shear stability and excellent thermal stability.
  • A very good viscosity-temperature behaviour.
  • An excellent aging resistance and high oxidation resistance.
  • A very good wear protection, excellent EP characteristics.
  • A low foaming even at high speeds.
  • Good compatibility with non-ferrous metals and sealing materials.
  • Good circuit behaviour at low temperatures, low pour point.
  • Longest oil change intervals, thanks to excellent shear stability.
  • Reduced noise transmission through low vibration even in hot oil through the oil film with good adhesion and excellent LS additive.

Technical Product Data

PropertyUnitDataAudit
Density at 20 °Ckg/m³864,0EN ISO 12185
ColourblauVISUELL
Viscosity at 100 °Cmm²/s27DIN 51562-1
Brookfield Viscosity at -40 °CmPa*s144.600ASTM D2983
Flashpoint°C204DIN EN ISO 2592
Copper Strip Test at 121 °C1aASTM D130

All indicated data are approximate values and are subject to the commercial fluctuations.
