RAVENOL Getriebeoel TGO SAE 75W-90 API GL 5

Category: Gear oil for manual transmissions and drive axis
Item number: 1222105
Viscosity: 75W-90
Specification: API GL-5, MIL-L-2105 D
Oil type: Semi-synthetic
Application: Passenger car, Truck

RAVENOL Transmission Oil TGO SAE 75W-90 API GL 5 is a semi-synthetic transmission oil specifically for maximum duty hypoid geared transmissions.

RAVENOL Transmission Oil TGO SAE 75W-90 API GL 5 is designed based on high-quality solvent refined and synthetic base oils and specially harmonised additive treatment with extreme pressure (EP) active ingredients and other additives. This exceeds the needs of today's application requirements.

Application Note

RAVENOL Transmission Oil TGO SAE 75W-90 API GL 5 is a maximum duty transmission oil for use in maximum duty, hypoid geared transmissions (axle drives, manual transmissions, etc.), where maximum duty transmission oils are required.

Characteristics

  • Excellent oxidation stability
  • Greatest possible protection from rust, corrosion, foaming
  • Low solidification point
  • Excellent extreme pressure (EP) properties
  • High viscosity index
  • Fuel savings

Technical Product Data

PropertyUnitDataAudit
Density at 20 °Ckg/m³842,0EN ISO 12185
ColourgelbVISUELL
Viscosity at 100 °Cmm²/s15,7DIN 51562-1
Viscosity at 40 °Cmm²/s97,3DIN 51562-1
Viscosity Index VI173DIN ISO 2909
Brookfield Viscosity at -40 °CmPa*s70.000ASTM D2983
Pourpoint°C-45DIN ISO 3016
Flashpoint°C215DIN EN ISO 2592
Copper Strip Test at 121 °C1bASTM D130

All indicated data are approximate values and are subject to the commercial fluctuations.
