Category:
Gear oil for automatic transmissions
Item number:
1212101
Specification:
MERCON® V
Oil type:
Synthetic
Approvals:
MERCON® V (Lizenznummer M5060502)
Recommendation:
Ford 8000045,
Ford ATF E-M5,
Ford WSS-M2C202-B,
Ford WSS-M2C919-E,
Ford XT-5-QMC,
Ford 1565889,
Ford 5014519,
Ford XT-5-5QM,
Ford XT-5-DMC
Application:
Passenger car
RAVENOL ATF MERCON® V is a synthetic ATF (Automatic Transmission Fluid), designed on the basis of high quality hydrocrack oils with a special additive and inhibition, which ensure a perfect function of the automatic transmission.
RAVENOL ATF MERCON® V guarantees a maximum of corrosion protection during any operating condition.
RAVENOL ATF MERCON® V is a ATF (Automatic Transmission Fluid ATF for automatic transmissions of FORD.
Application Note
RAVENOL ATF MERCON® V was especially developed for the use in automatic transmissions of FORD. It is recommended to flush with RAVENOL ATF MERCON® V before filling.
Characteristics
- a very good lubricating ability even at low temperatures in winter
- a high, stable viscosity index
- a very low pour point
- a very good oxidation stability
- as far as possible protection against corrosion and foam formation
- good balanced coefficient of friction
- neutral behaviour against sealing materials
- neutral behaviour because of inhibition against non-ferrous metals
Technical Product Data
| Property | Unit | Data | Audit |
|---|---|---|---|
| Density at 20 °C | kg/m³ | 847,0 | EN ISO 12185 |
| Colour | rot | VISUELL | |
| Viscosity at 100 °C | mm²/s | 7,2 | DIN 51562-1 |
| Viscosity at 40 °C | mm²/s | 34,8 | DIN 51562-1 |
| Viscosity Index VI | 178 | DIN ISO 2909 | |
| Brookfield Viscosity at -40 °C | mPa*s | 15.800 | ASTM D2983 |
| Pourpoint | °C | -48 | DIN ISO 3016 |
| Flashpoint | °C | 210 | DIN EN ISO 2592 |
All indicated data are approximate values and are subject to the commercial fluctuations.
