RAVENOL Getriebeoel EPX SAE 85W-140 GL-5

Category: Gear oil for manual transmissions and drive axis
Item number: 1223211
Viscosity: 85W-140
Specification: API GL-5, MIL-L-2105 D
Oil type: Mineral

RAVENOL Getriebeoel EPX SAE 85W-140 GL-5 is a lubricating oil for mechanical gears based on high quality and solvent refined base oils. Special extreme pressure (EP)-active substances and selected additives give excellent lubricating oil properties.

RAVENOL Getriebeoel EPX SAE 85W-140 GL-5 is designed for use with maximum duty, hypoid gearing gears (axel drive, manual transmission, etc.), so far extreme pressure gear oils are required.

Application Note

RAVENOL Getriebeoel EPX SAE 85W-140 GL-5 is designed for use in highly loaded, hypoid gears for hypoid gearbox, as well as for axle, transfer case, transmission gear, auxiliary gearboxes in vehicles and machinery and for use as extreme pressure gear oil where this grade of lubricant is specified by the manufacturer.

Characteristics

  • a very good oxidation stability
  • widest possible protection against rust and corrosion
  • no foam formation
  • excellent extreme pressure properties
  • low pour point
  • neutral behaviour towards metals and sealing materials

Technical Product Data

PropertyUnitDataAudit
Density at 20 °Ckg/m³894,0EN ISO 12185
ColourbraunVISUELL
Viscosity at 100 °Cmm²/s26,4DIN 51562-1
Viscosity at 40 °Cmm²/s355,0DIN 51562-1
Viscosity Index VI99DIN ISO 2909
Brookfield Viscosity at -12 °CmPa*s55.000ASTM D2983
Pourpoint°C-24DIN ISO 3016
Flashpoint°C224DIN EN ISO 2592
Copper Strip Test at 121 °C1bASTM D130

All indicated data are approximate values and are subject to the commercial fluctuations.
